DIY Corner TV Mount: Steps to Make A Corner TV Mount At Your Home

If you are wondering about setting up a TV in your small bedroom, then there are creative ideas you can try to mount a TV. If you want to arrange the TV unit in the corner, then follow the DIY Corner TV Mount steps to design your TV mount which you can set up in the corner.

Mounting a TV on the wall using the standard mounting stand is pretty easy. However, there are only a few choices you have when it comes to setting up the TV in the corner. This DIY Corner TV Mount tutorial will help you make a TV Mount for your Corners.


You can design a corner-mounting shelf to set up the Television set or can buy the corner mounting stand from the market. If you are a DIY enthusiast and want to learn how to make a corner TV Mount, then you must follow the step-by-step guidelines given below!

DIY Corner TV Mount: Steps to Design a Corner TV Mount

Step 1:

The first thing you need to do is find the right location to hang your Television. For that, you need to use the studs where you can mount the unit. Use a marker to mark up the location of the studs on the wall.

Step 2:

Now, take a 12-inch long wooden board and place it vertically in the direction of the stud. The wider side of the board must be faced the wall. Keep the stud in the center position and drill three holes to the board to fix it with screws to the wall. Follow the same procedure on the other side.


Step 3:

Now, use a 5-inch wooden screw and tighten the screw to the 12-inch board. If required you can use washers to tighten the screws. You can use the drill machine to screw up the 5-inch wooden screw to the board.

Step 4:

After this, measure the distance between these two vertical boards that we installed on two different walls. Put the measurement on a standard 2by4 wooden board and cut the board with a saw.

Step 5:

Place the 2by4 board on the vertical boards and put a 45-degree angle cut at both sides. Make sure to do this with perfection as the 2by4 board must be set properly on the vertical wooden boards.


Step 6:

Now, use a miter box to put the perfect cut on the 2by4 board. The front surface of the board must be longer than the rear board. The rear board should be at least 3 inches smaller than the front surface. The front side of the board must be the size of the vertically installed boards. This will fix the board properly to the corner.

Step 7:

After cutting down the boards, it is time to install them on the vertical boards. Make sure to use the drill machine to fix the boards to the vertical boards. You can use standard 3-inch wooden screws to install the outer boards.

Step 8:

Now, take out the standard wall mounting stand and find the center point of the newly created shelf. Mark up the holes by placing the mounting bracket of the Television on the wooden shelf. Use a drilling machine to put holes in the wooden box.

Step 9:

Fix the mounting bracket by using the standard half-inch screws. If required you can use washers to tighten the screws properly.

Step 10:

Now, hang your TV to the mounting bracket attached to the wooden shelf or the Corner TV Mounter we recently designed.

Step 11:

Make a proper wired connection to the nearest power outlet. You can even design a small wooden corner stand to put a set-top box and remote control at the corner in your room.

Apart from this, you can even cut down the tringle boards to make a box-type wooden construction. On the front, you can place the wooden board on which you can fix the mounting bracket to hang in the Television unit.

This is how you can design a DIY Corner, TV Mount. You can unleash your creativity by using different materials to make the corner tv mount. There are many creative ways which you can try out to wall hang a TV in the corner. You can even buy readymade corner TV mounting stands from the market to wall mount your TV.

Frequently Asked Questions:

What type of TV can I hang in the Corner?

You can hang only flat-screen TV in the corner using the DIY Corner TV Mount. Make sure you understand the standard wall mounting method of your Television first before you start designing your corner tv mount.

Can I use Flanges and Iron Pipes to design the Corner TV Mount?

Yes, you can! You can use flanges and iron pipes on which you can set up a triangle wooden board. Once the shelf is set up properly, you can place the TV on the shelf.

How to Mount Your TV in a Corner?

You can wall mount a TV in the corner of your room by designing a Corner TV Mount. Or you can purchase a ready-made TV Mount Stand to hang your TV in the corner.

How much does it cost to design a DIY Corner TV Mount?

You can design a DIY Corner TV Mount for less than $25 depending on the method and the materials you used. If you have a larger TV, the same would cost you around $50.

The Bottom Line:

If you are into carpentry work, you can design a DIY Corner TV Mount stand in many ways. However, the above-given method is the easiest. Anyone can try this method to create a corner TV mount with no special requirements.

Just follow the steps given in the above tutorial and place the TV in the corner of your room. If you know of any other such quick method to design a corner tv stand, then feel free to let us know in the comments section.
